Accumulator Datasheet

Tell us more about your accumulator requirements by answering the questions below.

"*" indicates required fields

Business Contact Information

Your Application Description

For braking systems, landing gear deployment, flight control actuation...etc

Technical Data

In order to properly size the accumulator, we must understand what displaced fluid volume is required from what high pressure to what low pressure, and over what temperature range. Please provide best approximation for unknown values if able.
Provide if known, otherwise state TBD; This is the system fluid volume that the accumulator needs to be capable of holding and/or expelling
Provide if known, otherwise state TBD; This will be 0 unless you wish some fluid remaining in the accumulator
Provide if known, otherwise state TBD
Provide if known, otherwise state TBD

Specifications

Provide if known, otherwise state TBD; Please specify for full and empty condition, if different
Provide if known, otherwise state TBD
Per ARP4378: Proof Pressure = 1.5x maximum operating pressure or 3x pre-charge pressure (whichever is higher)
Per ARP4378: Burst Pressure = 4x maximum operating pressure or 5x pre-charge pressure (whichever is higher)
Provide if known, otherwise state TBD; This will assist in determining if the design should be reviewed as adiabatic or isothermal

Sample information to include

  • Material Requirements (e.g. stainless steel, or titanium)
  • Fluid Type
  • Max Diameter (inch / cm)
  • Max Length (inch / cm)
  • Target Weight (lb / kg)
  • Mounting Requirements
  • Hydraulic Port Requirements
  • Sensing Required? (Level sensing, pressure sensing or temperature sensing)
  • Additional cycle definitions (e.g. partial stroke cycles)
